GebraBit ICP-20100



  • Module type: Barometric Pressure and Temperature module
  • Module Supply Voltage: 1.8 V or 3.3 V
  • Output type: Digital – I2C or I3C or SPI
  • Pressure range: 30 to 110 kpa
  • Pressure Resolution: 20 Bit
  • Operating temperature range: -40°C to +85°C
  • Package: GebraBit small (36.29mm x 32.72mm)



Add to wishlist
Compare
Add to wishlist
SKU: GB638EN Categories: Pressure, Products, Sensors
Share
  • Description
  • Specifications
  • Documents
Description

OVERVIEW

GEBRABIT ICP-20100 is a High Accuracy Barometric Pressure and Temperature Module.

GebraBit ICP-20100 module can operate with “1V8” or “3V3” supply Voltages by Considered “VDD SEL” jumper selector. Also there is an another jumper named “VDIO SEL “, which is regarded to select logic level voltage of module I/O pins between “1V8” or “3V3”. This feature helps to use a wide range of microcontrollers for interfacing with this module.

User can interface with GebraBit ICP-20100 by either I2C or SPI protocol. This is achieved by dedicated four jumper selectors on the top right of the GebraBit ICP-20100 module. Furthermore, the last jumper selector (Fifth) is considered for setting the I2c address.

Also, Users can access the interrupt pin of the ICP-20100 through the “int” pin of the GebraBit ICP-20100 module.

ICP-20100 is a sensor that provides a high-accuracy, low power, barometric pressure, and temperature sensor solution that integrates a capacitive pressure sensor for monitoring pressure changes in the range of 30 to 110 kPa.
The ICP-20100 can be configured to achieve ultra-low noise or ultra-low power performance and is flexible to perform anywhere in-between. Additionally, the filters can be enabled to allow even lower noise performance or activate features such as filtering of pressure glitches (e.g.opening/closing a window).

WARNING: FOR ACCURATE INFORMATION ABOUT ICs ABSOLUTE MAXIMUM RATINGS AND ITS PRECIOUS CHARACTERISTICS RANGES, USERS MUST CERTAINLY REFER TO ICs MANUFACTURE DATASHEET.

Key Features

  • Selectable module power supply and I/O logic voltage between1V8 and 3V3
  • On Board Selectable protocol between I2C and SPI
  • On Board Selectable I2C address
  • On Board, ON/OFF LED indicator
  • On Board LED indicator for sensor interrupt
  • GEBRABIT Pin Compatible with GEBRABUS
  • GEBRABIT small package
  • It can be used as a daughter board of GEBRABIT MCU Modules
  • Featuring Castellated pad (Assembled as SMD Part)
  • Separatable screw parts to reduce the size of the board

Pinout Diagram



GebraBit ICP-20100 pinout

Module Overview

GebraBit ICP-20100 parts



Specifications
Part Number

GebraBit ICP-20100

Short Description

GebraBit ICP-20100 is a Barometric Pressure and Temperature module, with Digital – I2C or I3C or SPI output and 30 kpa to 110 kpa and -20°C to +65°C measurment range

Board Type

Module

Module Supply Voltage

1.8 V or 3.3 V

Module Logic Voltage

1.8 V or 3.3 V

Module Current Consumption

10 mA to 30 mA (Typ. 20 mA)

Output Type

Digital – I2C or I3C or SPI

Pressure range

30 kpa to 110 kpa

Pressure Accuracy

–

Absolute Pressure Accuracy

±20 pa

Relative Pressure Accuracy

±1 hpa

Pressure Resolution

20 bits

Pressure Sensivity

–

Temperature Accuracy

± 0.5°C

Temperature Resolution

–

Humidity range

–

Relative Humidity Accuracy

–

Humidity Resolution

–

Operating temperature range

-40°C to +85°C

Package

GebraBit small (36.29mm x 32.72mm)

Brand

GebraBit

Documents

  • Schematic (.pdf)
  • Module Layout (.pdf)
  • ICP-20100 Datasheet
  • Wiki Link (Source Code and Tutorial)
DISCLAIMER: GEBRABIT PRODUCTS ARE INTENDED SOLELY FOR RESEARCH & DEVELOPMENT PURPOSES. GEBRABIT EXPLICITLY DECLARES IT HAS NO RESPONSIBILITY IF USERS UTILIZE THEM IN ALL OTHER SENSITIVE AND PRECISE APPLICATIONS THAT CAUSE FINANCIAL AND HUMAN LIFE DAMAGE.
